EQUIPMENT
Tool Room Equipment
- Makino DUO43 Wire EDM (2012)
- Charmilles Robofill 290P (2002)
- Charmilles FORM 20 EDM (1990)
- Eltee EDM machine (complete tooling)
- Jig Grinder Moore #3 (with complete tool cabinet)
- Jig Bore Atlantic #6000 Digital Readout (20' x 40' table)
- Jig Bore Moore #2 (complete tooling cabinet)
- Jig Bore Moore #3 (complete tooling cabinet)
- Okamoto Automatic Wet Surface Grinder (12" x 24" chuck, 1991)
- Harig Surface Grinder (6" x 12" Mag Chuck, 3 units, 1980–1985)
- Reid Surface Grinder (6" x 12" Mag Chuck, 2 units, Optical Radius & Form Dresser)
- Bridgeport Miller (FMM Head, 32" table, with readouts, self-programming control, 1990–1995)
- Kearney Trecker Horizontal Miller
- Bridgeport Rotary Table (with accessories)
- Hardinge HLV 10" Tool Room Lathe (1980)
- LeBlond Makino 15" x 54" Tool Room Lathe (1985)
- Nardine MS1440E Lathe (13" swing, 1993)
- Portable Drill Press (1/2" chuck, 2 units)
- LeLand Gifford 8-Speed Drill Press (24" table)
- Buffalo 4-Speed Drill Press (24" table)
- Cincinnati Bickford Radial Drill Press (52" arm)
- Pedestal Tool Grinder
- Dayton Sand Blaster
- Floor Model Arbor Press
- Power-matic Disc and Belt Sander
- Power-matic Band Saw (20")
- Framco 612 Cut-off Saw
- Kalamazoo Cut-off Saw
- Sunnen Honing Machine
- Rockwell Hardness Tester
- Granite Surface Plates (6 units, calibrated w/N.I.S.T.)
- Hand Tapping Machine
- Digital Height Checks (3 units, 0–14”)
Press Room Equipment
PRESSES:
- 150 Ton Precision Straight Side (with air feed)
- 150 Ton Bliss Straight Side (48" x 36", Roll Feed)
- 100 Ton Niagara Straight Side (2 units, Roll Feed)
- 100 Ton Niagara Long Bed (2 units, VAMCO Feed)
- 60 Ton Minster Press (with Air Cushion)
- 45 Ton Russell Press
- 60 Ton Minster Press (4 units)
- 45 Ton Federal Press
- 22 Ton Federal Press
- 150 Ton Flexo Press
Feeders & Stock Handling:
- Stock Uncoiler (4 units, 2000 lbs capacity)
- Power Stock Straightener (0–12")
- Power Stock Straightener (0–6")
- Air Power Stock Feeders (2 units)
Additional Equipment:
- Automatic tapping unit
- BODINE #42 Assembly & Test Equipment
- Automatic Gas Tungsten Arc Welders (2 units)
- Hydraulic Shear (M16 handguard)
- M16 Tabs Liner Finishing Machine
- Orbital Riveting Machines (2 units)
- Heat Treat Oven
- Benchtop assembly equipment (assorted)
CNC Department
- Makino Machining Center S33 (2003, Y-18", X-24")
- Hurco Machining Centers VM1 (2 units, 2006–2007, Y-14", X-26")
- Hurco Machining Center VM2 (2007, Y-20", X-40")
- Hurco Machining Center VM20 (2012, Y-20", X-40")
- Hurco Horizontal Machining Center HTX500 – HM 400 mm Twin Pallet (Y-22", X-19")
- Doosan Machining Centers HC200 – HM 400 mm Twin Pallet (4 units, Y-22", X-15")
- CNC Bridgeport 3 Axis E-Z Trak DX11 (2 units, 1987)
- CNC Harig Surface Grinders (2 units, 2005)
- Hurco Machining VM10
- Toyoda Horizontal Machining Center FH550SX – HM 550 mm Twin Pallet
- Doosan LYNZ220LSY Live Tooling Turning Center (320 mm Dia. x 500 mm Length Max)
- CMM Revolution (AIM5) 20" x 20" (2013)
- CMM Brown & Sharpe Micro Xcel 7.C.5 24" x 24" (2010)
- Granite Surface Plates (2 units, 36x48)
- Brown & Sharp 12" Height Check & Mitutoyo 12” Height Check
- Miscellaneous Inspection Equipment
Inspection Room
- CAD/CAM System 486-33MHZ
- Roland GRX-A-D Plotter
- Digital Computer
- A Gage Blocks & O Grade Gage Blocks
- Rockwell Hardness Tester
- Wagner Spring Tester
Micellaneous Support Equipment
- Tow Motor Fork Truck (3800 lbs)
- Lift Truck (2000 lbs)
- 1 Ton Gantry & Chain Hoist
- Lacy Die Trucks (2 units)
- Southwestern Die Trucks (2 units)
- 30 HP Rotary Air Compressors (2 units, Press Room)
- 40 Ft Storage Trailer
- United Scale (6600 lbs)
- Vibratory Finishing Machines (3 units)
- Electric Heat Treating Furnace
- Sandblasters (2 units, abrasive machining)
Quality Management Instruments
- Revolution 555 Automated CMM (3D model support)
- Brown & Sharpe Micro Excel 7.6.5 Manual CMM (with Nikon CMM Manager software)
- RAM Optical Instruments OMIS II Vision System
- MicroVu H-14 Digital Comparator
- Wilson Hardness Tester
- Wagner Force Gage
- Granite Surface Plate (36x48 Grade A)
- Mitutoyo 12” Height Gage
- Starrett Grade 0 Gage Blocks
- Deltronic Plug Gages
- Micrometers, Calipers, and other hand measuring tools
